SPECIFICATIONS
Standard in China
1GB150-1998 Steel pressure vessels
2GB/T19905-2005 Liquefied gas truck
3Pressure vessel safety technology and inspection procedures
4Liquefied gas tanker safety monitoring procedures
Tanker Essential Information
1Dimensions(length*width*height)13250*2500*3745(mm)
2Estimated Tare Weight17860KG
3Payload21840KG
4Total Weight39700KG
Shell Of Tanker
1ProductsLPG, Butane , Propane
2Fluid propertyflammable
4Design temperature                           -40°C to 50°C
5Design pressure               1.72MPa
6Corrosion allowance                                 1.0mm
7Major materials of bearing pressureTanker body : Q345R , 12mm
End plate : Q345R , 14mm
Main Beam : Q345B
8Filling weight per volume     420Kg/m3
9Maximum filling weight       21840Kg
10CompartmentsOne
11Baffle inside the tank14-off Aluminum bolted plate , thickness is 5mm
12ShapeCylindrical ; Ellipse head
Detection
1Heat treatmentOverall heat treatment in a furnace , 500°C to 560°C
2Flaw detection100% Flaw detection
3Hydrostatic test2.66MPa
4MagnafluxAim at welding place flaw detection can not cover
Manhole (As customer's requirement )
1Quantity1 ; On top
Safety Valve (As customer's requirement )
1QuantityTwo
2LocationOn the top of tanker ;
3TypeOnly weld suitable flange
4SizeAs customer's requirement
Liquid meter (As customer's requirement )
