Multi axles Lowbed Semi Trailer

BACK

Model No	Axles		Tires	Capacity
2lines4axles	4		16	80tons
3lines6axles	6		24	120tons
4lines8axles	8		32	150tons
Rated Load		80Tons-150Tons
Tare Weight		15T
Wheel Base		1310 (mm)
Tyre Specifications		10.00R20
No. Of the Tyres		32
Axle Brand		25Tonnage X FUWA Brand
No. Of the Axles		8 Axles
Pieces of leaf-spring		10
Suspension		Heavy Duty Leaf Spring
Front/Rear Overhang		1950 mm
Outside Dimensions		16500x3000x1500 (mm) (LxWxH)
Material of the Main Beam		Q345B/ST52-3 manganese plates, automatic submerged arc,Main-beam Height 500mm, Lower flange: 20mm Upper flange: 20mm Mid Web: 12mm
Usage		For heavy duty machine, as transformer, crane, excavator transportation.
Brake System		Dual Lines Braking System With Automatic Air Chambers
Brake Air Chamber		Four double and two single chamber
Electrical System		24V, 7core socket, lights according to European standards.
Floor		4mm management plate
Tool Box		1 box of standard tools
Spare tire carrier		2 sets
Color and Logo		By the buyer’s requirement.
The traction pin		2’ & 3.5’ inter-changeable
Pin Height		By height of the tractor saddle.
